Round Back Rotary Cutter
Series 240
Taylor Pittsburgh’s 240 SERIES ROUND BACK ROTARY CUTTERS are constructed using 11 gauge for the top sheet and 10 gauge on the side skirts for added strength. They come equipped with your choice of a 50 HP shear bolt or slip clutch gearbox. Available in 5’ and 6’ widths with Cat. I hitches. This is a quality manufactured cutter that can be purchased for an affordable price.
| STANDARD FEATURES | Extra Equipment Available: |
|---|---|
| Cat. I Hitch 11 Gauge Top Deck Thickness 10 Gauge Side Skirt Thickness 50 HP Gearbox Available in 5' and 6' widths |
Front Chain Guards Front Deflector Shields Slip Clutch |
Round Back Rotary Cutters
| Model | 245 | 246 | 365 | 366 | 486 | 487 |
|---|---|---|---|---|---|---|
| Cutting Width | 60" | 72" | 60" | 72" | 72" | 84" |
| Gearbox Rating | 50 HP | 50 HP | 60 HP | 60 HP | 90 HP | 90 HP |
| PTO RPM | 540 | 540 | 540 | 540 | 540 | 540 |
| Blades | ½" x 3" | ½" x 3" | ½" x 3" | ½" x 3" | ½" x 4" | ½" x 4" |
| Stump Jumper | Round | Round | Round | Round | Round | Round |
| Cutting Height Range | 2" to 10" | 2" to 10" | 2" to 12" | 2" to 12" | 2" to 12" | 2" to 12" |
| Gear Box Protection | SB or SC | SB or SC | SC | SC | SC | SC |
| Deck Material | 11ga | 11ga | 10ga | 10ga | 7ga | 7ga |
| Side Skirt Material | 10ga | 10ga | 7ga | 7ga | ¼" | ¼" |
| Side Skirt Depth | 7" | 7" | 8" | 8" | 9" | 10" |
| Tailwheel(s) | Single Laminated | Single Laminated | Single Laminated | Single Laminated | Single Laminated | Dual Laminated |
| Hitch | Cat. I | Cat. I | Cat. I | Cat. I | Cat. II | Cat. II or III |
| Deflector Shields | Optional | Optional | Not Available | Not Available | Not Available | Not Available |
| Chain Guards | Optional | Optional | Standard | Standard | Standard | Standard |
| Approx. Weight | 606 lbs. | 683 lbs. | 765 lbs. | 860 lbs. | 1163 lbs. | 1630 lbs. |
| Cutting Capacity | Up to 1" | Up to 1" | Up to 1.5" | Up to 1.5" | Up to 2" | Up to 2" |
| Minimum PTO HP | 20 HP | 30 HP | 30 HP | 35 HP | 50 HP | 60 HP |
