Wheel-Type Tandem Disc Harrow
Series 377
Taylor Pittsburgh’s Series 377 Tandem Disc Harrow is designed for medium to low acreage applications. Suitable for tractors from 30-60 HP. These discs feature a tubular frame in a weight class rugged enough for the farmer or landscaper, yet economical enough for the part-timer.
STANDARD FEATURES
- Heavy-Duty 3" x 3" Tubular Steel Frame
- 7 ½" Blade Spacing (9" Spacing Optional)
- 1" Square High Carbon Gang Axles
- Sealed Ball Bearings
- Durable Cast Spacer Spools
- Cat. I Straddle Mount, 3-Point Hitch
- Adjustable Gang Angle: 2.3˚, 11.3˚, 20.9˚, 27.8˚
- Available with all Cut Out, or Combination Discs
- Other Models Available
| Model | Number of Discs | Blade Diameter | Disc Spacing | Working Width | Approx. Weight | DB HP Required |
|---|---|---|---|---|---|---|
| 377-16-18-CF-77 | 16 | 18" | 7 ½" | 5 ½' | 808 lbs. | 30 HP |
| 377-16-20-CF-77 | 16 | 20" | 7 ½" | 5 ½' | 908 lbs. | 30 HP |
| 377-20-18-CF-77 | 20 | 18" | 7 ½" | 6 ½' | 823 lbs. | 40 HP |
| 377-20-20-CF-77 | 20 | 20" | 7 ½" | 6 ½' | 913 lbs. | 40 HP |
| 377-24-18-CF-77 | 24 | 18" | 7 ½" | 7 ½' | 914 lbs. | 50 HP |
| 377-24-20-CF-77 | 24 | 20" | 7 ½" | 7 ½' | 935 lbs. | 50 HP |
